LED Moving Head Fresnel light LS500W
The unique optical system design makes it have a high color rendering index (CRI ≥90, Ra≥92), which makes the actors' appearance on the stage perform better and brings a more realistic look and feel to the audience, while the adjustable zoom (12°–34°) and focus functions allow for different stage sizes, such as TV stations, broadcasts, and studio usage scenarios. The lighting technician can easily track the target through the console and perform linear color temperature adjustment to meet any needs of recording, taking photos, and live shows. It is fast and efficient, saving you labor costs. The LS500W moving head Fresnel delivers a high CRI≥90 and Ra≥92, ensuring the enhancement of actors' face color on the stage of the studio or theater, showing the best of the actors. At the same time, different from the fixed installation of traditional Fresnel or spotlight, if you want to track moving actors or targets, the traditional fixture will give the lighting technician a headache, and you may have to set up more light positions. With LQE LS500W, the lighting technician can easily track the target and perform linear color temperature adjustment to meet any needs of recording, taking photos, and live shows. It is fast and efficient, saving you labor costs.
- Description
- Specifications
- FAQS
Features:
-
450W COB LEDs light engine
-
High color rendering index CRI ≥90,Ra≥92
-
effect with variable speed up to 25 Hz, pre-programmed random strobe & pulse effects
-
Quiet, stable and fast moving system with re-positioning function
SOURCE | 450W LED light engine | EFFECTS | Motorized zoom |
20000 Hour Average LED Life* | Prism:none | ||
*Verify the lab’s settings. Many variables,
such as but not restricted to: environmental factors, power/voltage, usage behavior (on-off cycling), controlling, and dimming, may change. |
Electronic Frost: none | ||
PHOTOMETRIC DATA | Total Lumen Output :32000Lm | Motorized Dimming: 100% linear | |
CRI :≥90 | Motorized Focus : 0-100% linear | ||
Zoom range:12°— 34° |
Strobe system: effect with variable speed up to 25 Hz, pre-programmed random strobe
& pulse effects |
||
Illumination: Center brightness≥5200LUX@20M (65.6’)(5° Full ON)
spot diameter<1.5M |
Movement: Pan 540°, Tilt 270° (16/8 bit) | ||
COLOR | CMY Color Mixing | CONTROL / CONNECTIONS | DMX : 10 Ch |
CTO | Pan/Tilt (16/8 bit) | ||
Color temperature:2800K – 6500K |
DMX, RDM protocol support, master-slave
sound control, auto |
||
Color:CTO 2800K – 6500K | 4 touch buttons, 1.8-inch LCD control panel | ||
Fixed gobo:none | 180° Reversible LCD Menu Display | ||
GOBOS | Rotating gobo:none | Electronic Dimmer:0-100% linear | |
SIZE / WEIGHT |
Size:L420×W300×H598(mm)
(16.5‘’x 11.8‘’x23.5‘’) |
Motorized Focus:0-100% linear | |
Weight:43.4lbs(19.7KG)(including clamps) | Energy saving mode | ||
ELECTRICAL | Rated Voltage:AC 100-240V 50/60Hz | IP20 NEUTRIK DMX XLR In/Out | |
Rated Power:Max Power Consumption 550W | IP20 PowerCon 16A In/Out | ||
Power Factor:0.95 | Physical Features |
Flame retardant, high temperature resistant
PC+ABS shell |
|
Working temperature:32°F to 104°F (0°C to 40°C) | Folding integrated, rotatable light clamps | ||
INCLUDED ITEMS | IP20 NEUTRIK DMX XLR 1.5M x 0.75mm² In/Out | APPROVALS / RATINGS | CE pending| CETLus pending | IP20 |
IP20 PowerCon 1.5M x 1.5mm² 16A In/Out | |||
Satefy rope |
- Q Does LQE Offer Customized Stage Moving Light Solution?
-
A An experienced R&D team can provide customized digital stage lighting OEM/ODM solution service to meet clients’ unique demands from global markets, such as customized CRI parameter, Ingress protection rating, effect, etc.
- Q Can I Have a Sample Order for Led DJ Light?
-
A Sure, sample order are welcome to test and check LQE quality. Mixed samples are acceptable.
- Q What Kind of Certificates You Offer?
-
A All kinds of certificates could be offered by LQE digital moving light factory, which depends on customer’s required, different pricing plan for different approval.
- Q What Is the Warranty Offered by LQE Lighting?
-
A LQE lighting offers a comprehensive 1-year warranty and spare parts on its products, giving customers peace of mind and investment protection.
- Q Does LQE Offer a Stage Light Design Solution?
-
A LQE experienced team glad to supply a stage lighting configuration design solution or suggestion for projector who don’t have much experience in lighting design, project, theatre and studio.
- Q Do You Supply After-Sale Service?
-
A LQE lighting offers 7x24 hrs systematic SOP customer support with dedicated personnel, ensuring quick and comprehensive assistance for stage lighting needs.
